BX Cable (AC 90)

This AC90 interlocked aluminum armoured BX cable complies with CSA C22.2 NO2556 Canadian standard, specially designed for fixed power wiring in residential and commercial construction projects of Canada.

✅ Standard: CSA C22.2 NO2556 Canadian armored building wire standard

✅ Rated Voltage: 600V, general voltage grade for building power distribution

✅ Conductor: Solid copper conductor, stable conductivity and low heat loss

✅ Insulation: XLPE cross-linked polyethylene insulation, heat resistant up to 90℃

✅ Wrapping Layer: Paper tape wrapping protects inner insulation from friction damage

✅ Armour: Interlocked aluminum metal sheath, anti-crush, anti-impact and rodent resistant

✅ Max Operating Temperature: 90℃, stable performance for long-term indoor laying

It is the mainstream armored wiring cable for Canadian residential concealed and exposed circuit layout, widely used for villa, apartment and commercial building power distribution engineering!
